U-SCAN BOLT™
Make self-service available at any touchpoint
Self-Service Everywhere
Today’s retail store is a constantly evolving environment of emerging business challenges coupled with increasing operational demands. With self-service being called upon to solve these problems, retailers need a system that can adapt as needed. U-SCAN BOLT™ is designed to tackle a retailers’ need for flexible solutions that provide easily deployable self-service applications throughout their in-store environment. With Fujitsu, you can simply BOLT™ it and forget about it.
Self-Service Everywhere
Today’s retail store is a constantly evolving environment of emerging business challenges coupled with increasing operational demands. With self-service being called upon to solve these problems, retailers need a system that can adapt as needed. U-SCAN BOLT™ is designed to tackle a retailers’ need for flexible solutions that provide easily deployable self-service applications throughout their in-store environment. With Fujitsu, you can simply BOLT™ it and forget about it.
Explore U-SCAN BOLT™
- Compact footprint allows retailers to offer self-service at any touchpoint in the store
- Sleek, minimalist design blends into any store decor
- Pedestal and counter mounting options for maximum flexibility in terms of installation
- Flexibility to be used from the simplest ticket-queuing applications to complex quick-service solutions
- Multiple mounting configurations simplifies deployment
- Pedestal, Counter-top
- Unified components reduces TCO while increasing reliability
- Common with Fujitsu POS, SCO, Convertible Lanes
- Compatible with all Fujitsu S3 solutions
- QSS, SCO, SmartCASH, Verso, TaskForce, Integro, etc.
| Dimensions | |
| Counter-Top | 300mm W x 575mm H x 238mm D |
| Pedestal | 500mm W x 1278mm (for 15" monitor) or 1469mm (for 19" monitor) H x 405mm D |
| CPU | |
| CPU Type | Intel® 10th Generation Core™ i3-10100E 65w Ice lake |
| Memory | 16GB Standard memory, expandable to 64GB |
| Storage | 128 GB PCIe® NVMe™ |
| Ethernet | Intel® I219-LM GbE, Realtek RTL8153AH GbE; WLAN: Intel® Wi-Fi 6 AX201 (2x2) and Bluetooth® 5 combo, non-vPro®; Intel® Wi-Fi 6 AX201 |
| Inputs/Outputs | Advance Hub: 1 Cash drawer connector, 2 power serial, 4 SuperSpeed USB Type-A 10Gbps signaling rate, 1 RJ-45 USB NIC, 1 DC connector, 2 SuperSpeed USB Type-C® 5Gbps signaling rate (27W USB Power Delivery, Alt Mode DisplayPort™), 1 140W data port, 2 12v PUSB port, 1 24v PUSB port |
| Display Options | 39.6 cm (15.6”) diagonal, FHD (1920 x 1080), touch, IPS, anti-glare, 400 nits, 45% NTSC; or 49.5 cm(19.5”) diagonal, FHD (1920 x 1080), touch, VA, anti- glare, 450 nits, 72% NTSC |
| Scanner | Datalogic 1500i 1D, 2D, PDF, QR, supports EAS |
| Printer | Epson TM-m30II 80mm printer, 250mm/s |
| LED Lighting | LED Lighting Platform |
| Assist Shelf | Optional side shelf, left or right mount |
| Operating System | Microsoft Windows10 LTSC 2019 OS |
| Power | |
| Voltage | 280 W external Smart AC power adapter, up to 89% efficiency, active PFC (Advance Hub) |
| Frequency | 50/60 Hz |
| Environment | |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) 15° C/Hr (Non-Condensing) |
| Non-operating Temperature | 23°F to 122°F (-5°C to 50°C) |
| Operating Relative Humidity | 10 to 90% non- condensing |
| Non-operating Relative Humidity | 9 to 95% non- condensing |
Data Sheet
Fujitsu U-SCAN BOLT™
With its minimalist design and small footprint, U-SCAN BOLT allows for self-service to be implemented anywhere while flawlessly blending into any store décor and layout. U-SCAN BOLT offers multiple configurations, including pedestal and countertop mounting options, so it is simple to deploy anywhere self-service is needed.
Data Sheet
Fujitsu U-SCAN BOLT™
With its minimalist design and small footprint, U-SCAN BOLT allows for self-service to be implemented anywhere while flawlessly blending into any store décor and layout. U-SCAN BOLT offers multiple configurations, including pedestal and countertop mounting options, so it is simple to deploy anywhere self-service is needed.
Talk to an industry expert
Explore Fujitsu U-SCAN BOLT™ with one of our retail technology experts. Contact us to learn more.
