U-SCAN Express+
Sleek, compact cashless self-checkout unit
Plussing the self-service experience
Fujitsu continues to lead the digital transformation of retail with the launch of U-SCAN Express+. U-SCAN Express+ is designed from the ground up for maximum flexibility for accepting cashless payments. The compact footprint and minimalist aesthetic allow retailers to add multiple units in a small space, creating high throughput self-checkout environments, and thus enhancing the customer experience. Combined with industry-leading technology from HP, U-SCAN Express+ performs fast cashless transactions at lightning speed.
Plussing the self-service experience
Fujitsu continues to lead the digital transformation of retail with the launch of U-SCAN Express+. U-SCAN Express+ is designed from the ground up for maximum flexibility for accepting cashless payments. The compact footprint and minimalist aesthetic allow retailers to add multiple units in a small space, creating high throughput self-checkout environments, and thus enhancing the customer experience. Combined with industry-leading technology from HP, U-SCAN Express+ performs fast cashless transactions at lightning speed.
Plussing the self-service experience
Fujitsu continues to lead the digital transformation of retail with the launch of U-SCAN Express+. U-SCAN Express+ is designed from the ground up for maximum flexibility for accepting cashless payments. The compact footprint and minimalist aesthetic allow retailers to add multiple units in a small space, creating high throughput self-checkout environments, and thus enhancing the customer experience. Combined with industry-leading technology from HP, U-SCAN Express+ performs fast cashless transactions at lightning speed.
Explore U-SCAN Express+
Benefits
- Compact footprint and minimalist aesthetic allow retailers to add multiple units in a small space
- Designed from the ground up for maximum flexibility for accepting cashless payments at lightning speed
- Provides a full self-service experience without the friction involved with learning curves
- Engineered to simplify upgrading and modifying the device well into the future
- Provides the flexibility and reliability needed in modern retail technology
Features
- Small footprint enables high throughput self-checkout
- Performs cashless transactions at lightning speed
- Multiple configurations available
- Leading HP technology provides maximum responsiveness
- U-SCAN software provides familiar experience for customers
Specifications
| Dimensions (W x D x H) | 325mm x 669mm x 2471mm |
| Weight (without bills) | Approx. 170kg |
| CPU | Type: Intel® 14th Generation Core™ i3-1110G4 Ice lake Chipset: Intel® Celeron® G6900TE |
| Memory | 2 SODIMM Memory slots with up to 64 GBDDR5 SDRAM |
| Storage | 256 GB to up to 4 TB PCIe® NVMe™ |
| LAN Ethernet | Intel® I219-LM GbE, vPro®; Realetk RTL8153CH GbE WLAN: Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card Intel® Wi-Fi 7 BE200 |
| Inputs/Outputs | 3x USB Type-A 5Gbps signaling rate 1x RJ-45 NIC 1x DCconnector 3x USB 2.0 Type-A 1x USB Type-C® 5Gbps signaling rate (27 WPower Delivery, Alt Mode DisplayPort™ ) 1x 140Wdata port 1x P-USB 12V 1x P-USB 24V |
| Display Options | 39.6 cm (15.6”) diagonal, FHD (1920 x 1080), touch, IPS, anti-glare, 400 nits, 45% NTSC; or 49.5 cm(19.5”) diagonal, FHD (1920 x 1080), touch, VA, anti- glare, 450 nits, 72% NTSC |
| Scanner Scale | High performance 1D and 2D bar code bioptic scanner (EAS supported) Maximum Static Weight: Up to 300lb / 136 kg depend on model |
| Printer | Epson TM-M30II thermal 80mm printer |
| Lane Light | White color lane number light Tri-color indicator light |
| Operating System | Windows10 LTSC 2019 and Windows10 LTSC 2021 |
| SDK | Fujitsu Control Library (Optional) |
| Electrical Requirements | 100-240V AC; 3A; 50/60 Hz/span> |
| Temperature Operation | Operation: 32°F to 104°F (0°C to 40°C) Non-operating: 23°F to 122°F (-5°C to 50°C) |
| Humidity Operation | Operation: 10 to 90% non-condensing Non-operating: 8 to 95% non-condensing |
| Security Rating | Business Hours |
| Compliance | UL, CSA, FCC, RoHS, REACH, CE |
Fujitsu Frontech North America reserves the right to change specifications without notice
Data Sheet
Fujitsu U-SCAN Express+
U-SCAN Express+ personifies unified commerce hardware solutions. Built with the same sleek, modern design as the U-SCAN Venture, U-SCAN Express+ allows a retailer to deploy a sophisticated, familiar look throughout the retail environment. A common look and feel across all self-service devices ensure your customer always knows what to do. After all, your customers came to shop and pay, not struggle with technology. S3 solutions not only reduce estate management costs, they reduce interventions to free up labor for more important revenue-generating activities.
Data Sheet
Fujitsu U-SCAN Express+
U-SCAN Express+ personifies unified commerce hardware solutions. Built with the same sleek, modern design as the U-SCAN Venture, U-SCAN Express+ allows a retailer to deploy a sophisticated, familiar look throughout the retail environment. A common look and feel across all self-service devices ensure your customer always knows what to do. After all, your customers came to shop and pay, not struggle with technology. S3 solutions not only reduce estate management costs, they reduce interventions to free up labor for more important revenue-generating activities.
Data Sheet
Fujitsu U-SCAN Express+
U-SCAN Express+ personifies unified commerce hardware solutions. Built with the same sleek, modern design as the U-SCAN Venture, U-SCAN Express+ allows a retailer to deploy a sophisticated, familiar look throughout the retail environment. A common look and feel across all self-service devices ensure your customer always knows what to do. After all, your customers came to shop and pay, not struggle with technology. S3 solutions not only reduce estate management costs, they reduce interventions to free up labor for more important revenue-generating activities.
Talk to an industry expert
Explore Fujitsu U-SCAN Express+ with one of our retail technology experts. Contact us to learn more.
