WT-A533G RFID Garment Tag

Fujitsu’s low-cost Garment Tag for work wear, uniforms, and rental garments

Compact UHF RFID Tag for accurate tracking

Fujitsu’s latest UHF RFID garment tags are just 0.6mm thick, allowing for insertion into virtually any article of work wear, uniforms, and rental garments for food and beverage providers, manufacturing plants, healthcare institutions, hotels, and more. The Garment Tag uses advanced antenna technology that allows for reading hundreds of items while reducing misreads of nearby tags.



Compact UHF RFID Tag for accurate tracking

Fujitsu’s latest UHF RFID garment tags are just 0.6mm thick, allowing for insertion into virtually any article of work wear, uniforms, and rental garments for food and beverage providers, manufacturing plants, healthcare institutions, hotels, and more. The Garment Tag uses advanced antenna technology that allows for reading hundreds of items while reducing misreads of nearby tags.



Explore Fujitsu’s RFID Garment Tags

Benefits

  • UHF efficiency increases tag read performance to read hundreds of tags in a single pass
  • Perform inventory management accurately and easily by reading multiple tags at once with very low error rates
  • Installation of UHF technology will provide cost-effective garment management by reducing labor costs associated with barcode or high frequency RFID tags
Features

  • New, smaller form factor at just 0.6mm thick
  • Virtually transparent
  • Easy attachment with heat seal labels
  • Adhesive layer simplifies installation process
  • Advanced antenna technology provides bulk reading
  • Cost effective for easy adoption
Specifications
Model Fujitsu RFID Tag WT-A533G
Standard RFID Standard ISO/IEC 18000-63 (EPC Gen2)
Regulations RoHS Conforms to RoHS regulations
China RoHS Conforms to Administrative Measure on the Control of Pollution Caused by Electronic Information Products
MRI Safety Information MR Conditional (Static magnetic field of 1.5-T and 3-T)
Size & Weight 55 (W) x 9 (D) x 0.6 (H) mm, 0.4g
Tag Type Passive
EPC Number Area 128bit / unlock (The first 96bit are pre-written by Fujitsu)*1
User Memory None
Reading Range 902-928 MHz 4W eirp: 190 cm (Typical) Air; 230 cm (Typical) with heat seal
2W erp: 170 cm (Typical); 200 cm (Typical) Air
865.6-867.6 MHz 2W eirp: 100 cm (Typical) Air; 130 cm (Typical) with heat seal
Tagging Heat sealing, seam insertion, pouch
Estimated Lifetime 100 washing cycles/dry cleaning or 3 years from shipping date without usage, whichever comes first *2
Environmental Resistance Washing Method Laundry, Standard Detergent, Softener, Bleach (Oxygen/ Chlorine), Alkali*3
Dry cleaning (PERC and petroleum based solvents)*4
Heat Resistance Drying 85 ºC (Up to 60 min.) or 120 ºC (Up to 20 min.)
Ironing 200 ºC (Up to 10 sec. with press cloth)
Humidity/Temperature Operating -20 to 50 ºC, 10 to 95% RH
Storage -40 to 55 ºC, 8 to 95% RH
All data are results performed in our test condition according to Japan Industrial Standard JIS L 0217 - 102, 301, 401, 402. Your test result may vary. *1: Last 32 bits are not specified. Modifying EPC area is not covered by product warranty. *2: Verified with independent testing - nominal industrial laundry conditions *3: Conditions for washing: Conventional washers/dryers excluding water extraction press *4: Conditions for dry cleaning: Up to 10 minutes/cycle for washing, and 30 minutes/cycle up to 60 ºC for drying
WT-A533G preview

Data Sheet

WT-A533G RFID Garment Tag

Fujitsu’s RFID Garment Tag drives efficiency greatly in management works by simplifying processes such as inventory management with bulk reading at near 100% accuracy. The tag is designed for typical garment industrial laundry and dry-cleaning equipment and processes. Garment rental owners will see improved asset tracking and reduced loss, while keeping their costs low by improving workflow and efficiency.

WT-A533G preview

Data Sheet

WT-A533G RFID Garment Tag

Fujitsu’s RFID Garment Tag drives efficiency greatly in management works by simplifying processes such as inventory management with bulk reading at near 100% accuracy. The tag is designed for typical garment industrial laundry and dry-cleaning equipment and processes. Garment rental owners will see improved asset tracking and reduced loss, while keeping their costs low by improving workflow and efficiency.
